RM352 NVMe Gen4
3U NVMe 短深度邊緣計算伺服器機箱
3U 6-Bay NVMe Gen 4 短深度伺服器機箱專為全高擴展和靈活的熱插拔風扇插入而設計,為邊緣運算提供無與倫比的 GPGPU 馬力。
比較
快速搜尋
  • 依據機殼形式
  • 依據主機板
  • 依據磁碟陣列卡
  • 依據電源供應器
比較
特點與利益
  • 450 mm ultra-short chassis fits various environments and is perfect for footprint minimization.
  • Optimized I/O design for machine learning in edge sites offering up to eight full-height PCIe expansion slots for GPU/FPGA accelerator cards.
  • Equipped with the latest tool-less design, storage, HDD trays, system fans, and PCIe riser brackets for easy NVMes and maintenance.
  • 3U 6-Bay NVMe Gen 4 Edge Computing Chassis (1600W 1+1) /3U 6-Bay NVMe Gen 4 Edge Computing Chassis/Option: 2-Bay NVMe Gen 4 H/S module.
  • Specification
  • Download
  • Accessory
  • Compatibility
  • Order Information
  • 主機板尺寸 SSI EEB (12” x 13”), CEB (12" x 10.5"), ATX (12" x 9.6")
    外觀尺寸 (深 x 寬 x 高) 450.0 x 438.0 x 131.0 (mm) ; 17.72” x 17.24” x 5.15”
    儲存媒體插槽 2.5" HDD, Hot-Swap, Front :6
    2.5" HDD, Hot-Swap, Rear (Option):2
    電源供應器 2U Redundant CRPS (1+1), 1600W (80+, Platinum)
    前置指示燈 1 x Power Status , 2 x LAN Activity , 1 x UID , 1 x HDD Status , 1 x System Alarm
    前置控制 1 x Power On/Off, 1 x System Reset, 1 x UID, 1 x USB 3.0
    擴充槽 8 x Full Height (4 x Double-width GPU)
    硬碟熱插拔背板 3 x 2 Port NVMe Gen 4 (U.2) Option: 2 Port NVMe Gen 4 (U.2)
    淨重 11.595 KG/PCS
    毛重 15.1 KG/CTN
    材積 3.39
    裝櫃數量(單包) 20' FCL: 154 PCS / 40' FCL: 336 PCS
  • 類別 規格敘述 版本 大小 下載
    Datasheet RM352 NVME Gen4 Datasheet v1.0 v1.0 772.9 KB
  • 產品類別 料號 規格敘述 支援
    Click Part. No# to view item picture
  • 訂購碼
    RM35206H04*15869
    RM35206H04*15870
