RM252 Series
2U 可擴充短機身邊緣運算伺服器機殼
2U 短機身伺服器機殼，專為雙CPU主機板設計及支援熱插拔風扇配置，可極大化邊緣運算效能，以助力IT分散式系統建置。
比較
清除 執行
快速搜尋
  • 依據機殼形式
  • 依據主機板
  • 依據磁碟陣列卡
  • 依據電源供應器
搜尋
比較
特點與利益
  • 450 mm ultra-short chassis fits various environments and is perfect for footprint minimization.
  • Optimized I/O design for machine learning in edge sites offering up to three full-height or seven low-profile PCIe expansion slots for GPU/FPGA accelerator cards
  • Equipped with the latest tool-less design, storage, HDD trays, system fans and PCIe riser brackets for easy upgrades and maintenance.
  • Specification
  • Download
  • Accessory
  • Compatibility
  • Order Information
  • 主機板尺寸 SSI EEB (12” x 13”), CEB (12” x 10.5”), ATX (12” x 9.6”)
    外觀尺寸 (深 x 寬 x 高) 450.0 x 438.0 x 87.0 mm; 17.72” x 17.24” x 3.43”
    儲存媒體插槽 RM25206/FIO (2.5" Hot-swap)：6
    RM25204/RIO (2.5" Hot-swap)：4
    電源供應器 2U 800W 1+1 CRPS
    前置指示燈 1 x Power Status, 2 x LAN Activity, 1 x UID,
    1 x HDD Status, 1 x System Alarm
    前置控制 1 x Power On/Off, 1 x System Reset, 1 x UID, 1 x USB 3.0
    風扇 Rear : 80 mm (4), 11000 RPM
    up to T=38 mm, Hot-swap
    擴充槽 3 x Full Height or 7 x Low Profile
    硬碟熱插拔背板 RM25206/FIO:
    -2.5” 6-port 12Gbps SAS/SATA
    RM25204/RIO:
    - 2.5” 2-port 12Gbps SAS/SATA
    - 2.5” 2-port PCIe Gen3 NVMe
    - 2.5” 2-port PCIe Gen4 NVMe
    淨重 9.5 KG/PCS
    毛重 12.5 KG/CTN
    材積 2.80
    裝櫃數量(單包) 20' FCL: 208 PCS / 40' FCL: 448 PCS
  • 類別 規格敘述 版本 大小 下載
    Datasheet RM252 upgrade Datasheet V1.0 489.5 KB
  • 產品類別 料號 規格敘述 支援
    Click Part. No# to view item picture
  • 訂購碼
    RM25204 RIO : RM25204H01*15624
    RM25206 FIO : RM25206H02*15621
