RM24200
2U 高組裝彈性工業電腦機殼
RM24100設計是採用標準、主流規格的元件，並捨棄部分不常使用的工控機箱規格，而讓磁碟組態更多元、更富彈性。
比較
特點與利益
- 18"的機殼深度，適合空間有限的應用環境
- 風扇設置的優化，有效提升散熱效率
- 具防震功能的3.5"硬碟支架與光碟機支架
- 側邊滑道設計，讓硬碟與磁碟支架安裝更容易
- 支援PS/2電源及其他標準元件，降低整體成本
- 規格
- 下載
- 選配件
- 相容列表
-
主機板尺寸 uATX (9.6” x 9.6”) 外觀尺寸 (深 x 寬 x 高) 457.0 x 430.0 x 88.1 (mm)
18.00" x 16.93" x 3.47"儲存媒體插槽 External 5.25"：2
External 3.5"：1
Slim ODD：1
Internal 2.5"：2
電源供應器 PS/2 Single (Rear) 前置指示燈 1 x Power Status
1 x HDD Status
2 x LAN Activity前置控制 1 x Power On/Off
1 x System Reset
2 x USB2.0/USB3.0 (Option)系統安全裝置 Intrusion switch (Option) 風扇 Front: 1 x 80mm (T=32mm), Rear: 2 x 40mm (T=28mm) (Option) 擴充槽 4 x Low Profile 硬碟熱插拔背板 N/A 淨重 6.9 kg/15.2 lb 毛重 9.3 kg/20.48 lb 面板 Aluminum bezel frame or two-door bezel with air filter 材積 2.50 裝櫃數量(單包) 20': 388, 40': 788, 40'H: 940 -
類別 規格敘述 版本 大小 下載 Datasheet RM24200 Datasheet V1.2 1.1 MB
User Manual LED Board(80H03324101A0), Features and Jumper Settings V1.0 762.6 KB
User Manual RM24200 Quick Installation Guide V1.1 589.3 KB
-
產品類別 料號 規格敘述 支援 Cable 26H11324102A0 Cable, PSU, Wire Extension, 24P to 24P, 250mm Cable 26H11324103A0 Cable, PSU, Wire Extension, 8P to 4P+4P, 400mm Cable 84H324110-010 Cable, Intrusion, 2-Pin, 500mm Drive Cage 84H324110-007 Drive cage, 1x5.25"+1x slim ODD bays, exposed Drive Cage 84H324110-008 Drive cage, 1x5.25"+1x3.5" bays, exposed Fan 30H080032-101 FAN, 1pcs YS 80x32 Ball Bering , L300mm (3P3C), For Rear Window Fan 30H080032-112 FAN, 1pcs YS 80x32 Ball Bering , L300mm (4P4C),For Rear Window Fan 84H324210-003 FAN, 1pcs, AVC 40x28 Ball Bering, L310mm (4P4C), For Rear Window Power Supply 32H1030000706 PSU, 300W, PS/2 Single, FSP300-70PFL, 80+, w/80mm fan Power Supply 32H1030001104 PSU, 300W, PS/2 Single, Acbel PC7036-7H1G, 80+, w/80mm fan Slide Rail 84H323610-034 26“, P2P:22.1" to 35.8", Traveling Distance 27.5", Loading Weight 45.0 Kg, Tool-less Slide Rail 84H341300-002 Slide Rail, 21.9",For 2U/3U/4U
