| 主機板尺寸 |
ATX (12” x 9.6”), uATX (9.6” x 9.6”) |
| 外觀尺寸 (深 x 寬 x 高) |
409.0 x 438.5 x 43.2 (mm) |
| 儲存媒體插槽 |
External: 2 x 2.5" HDD, Hot-swap, Front：
|
| 電源供應器 |
1U Single 500W (80+ Gold)
|
| 前置指示燈 |
1 x Power Status, 1 x HDD Activity
|
| 前置控制 |
1 x Power On/Off, 1 x System Reset, 2 x USB 3.0
|
| 系統安全裝置 |
Intrusion Switch (Option)
|
| 擴充槽 |
1 x PCIe x16 Riser Card, Supporting Full Height & Half Length
|
| 硬碟熱插拔背板 |
2-Port 12G SAS/SATA Backplane
|
