RB251 Eagle Stream

適用於企業和雲端應用的 1U 高性能計算伺服器

最新的 2U 機架式準系統伺服器使用第四代 Intel® Xeon® Scalable 系列處理器，旨在成為滿足主流需求的主要主力伺服器。

比較

清除執行

快速搜尋

搜尋

比較

特點與利益

Supports M/B size up to 18.9 " x 16.9"
4th Gen Intel® Xeon® Scalable processors, Sapphire Rapids Series Processor, Dual Socket E LGA4677
High performance SAS/SATA/NVMe Gen 4 storage, up to 24 x 2.5” or 12 x 3.5” HDD
1+1 redundant CRPS, Max. 2100W

Higher memory capacity, up to 12TB memory, 16 DDR5 RDIMMs per processor.
1.5X memory bandwidth vs prior gen, with DDR5 support.
2X I/O throughput vs. prior gen, with PCIe 5.0 support

Specification
Download
Accessory
Compatibility
Order Information

機殼高度	Intel® Server Board M50FCP2SBSTD (18.9" x 16.9")
主機板	Intel M50FCP2SBSTD (Fox Creek Pass)
處理器	4th Gen Intel Xeon Scalable product family ; Dual Socket-E LGA4677
晶片組	C741
記憶體容量	32 DIMMs (16 per CPU), 8 channels; Supports DDR5 , SDRAM DDR5 DIMMs (RDIMM, 3DS-RDIMM, & 9x4 RDIMM)
外觀尺寸 (深x 寬 x 高)	770.0 x 438.0 x 87.0 mm; 30.3” x 17.24” x 3.4”
儲存媒體插槽	2.5” SKU SFF Hot-Swap (Tray-less：24 3.5” SKU LFF Hot-Swap (Tool-less)：12
電源供應器	1+1 Max. 2100W CRPS Redundant Power Supply
前置指示燈	1 x Power Status, 1 x UID,1 x HDD Activity, 1 x System Status
前置控制	1 x Power On/Off, 1 x System Reset, 1 x UID, 1 x USB 3.0,1 x USB2.0
系統安全裝置	Option
風扇	6 x 6038, 23000RPM, Hot Swap
擴充槽	Riser Slot #1: 1 x single-width slot (Intel NVMe riser card iPC FCP2URISER1RTM) Riser Slot #2: Two-Slot PCIe* Riser Card for Riser Slot #2 ((iPC FCP2URISER2STD) Riser Slot #3: Two PCIe NVMe SlimSAS connectors with re-timers(Intel NVMe riser card iPC CYPRISER3RTM) *Option:1 x Full Height and Full Length (Intel FCP2URISER1STD 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 16 supported) 1 x Full Height and Half Length (Intel FCP2URISER1DW 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 16 supported) 1 x Full Height and Full Length (Intel FCP2URISER1SWv 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 16 supported) 1 x Full Height and Half Length (Intel FCP2URISER2DW 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 16 supported) 2 x Full Height and Full Length (Intel FCP2URISER1SW 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 16 supported) 2 x Low Height and Half Length (Intel FCP2URISER3STD 1 x PCIe 5.0 x16 & 1 x PCIe 5.0 x 8 supported)
硬碟熱插拔背板	2.5” SKU: 3 x 8-port 2.5” NVMe(Gen4) 16 Gb/s NVMe support. (optionals:16 or 8 Bay ) 3.5” SKU: 12 x 3.5" Tri-mode hot-swap HDDs (SAS / SATA / NVMe Gen4) backplane applications.(8T4S)
淨重	23.1 KG/PCS
毛重	32.5 KG/PCS
