Chenbro - 產品

RB151 Eagle Stream

適用於企業和雲應用的 1U 高性能計算伺服器

最新的 1U 機架式準系統伺服器使用第四代 Intel® Xeon® Sapphire Rapids 系列處理器，旨在成為滿足主流需求的主要主力伺服器。

比較

清除執行

快速搜尋

搜尋

比較

特點與利益

Supports M/B size up to 18.9 " x 16.9"
4th Gen Intel® Xeon® Scalable processors, Sapphire Rapids Series Processor, Dual Socket E LGA4677.
High performance NVMeGen 4 storage, up to 12 x 2.5” or 4 x 3.5” HDD
1+1 redundant CRPS, Max. 1600W

Higher memory capacity, up to 12TB memory, 16 DDR5 RDIMMs per processor.
1.5X memory bandwidth vs prior gen, with DDR5 support.
2X I/O throughput vs. prior gen, with PCIe 5.0 support.

Specification
Download
Accessory
Compatibility
Order Information

機殼高度	Intel® Server Board M50FCP2SBSTD (18.9" x 16.9")
主機板	Intel M50FCP2SBSTD (Fox Creek Pass)
處理器	4th Gen Intel Xeon Scalable product family; Dual Socket-E LGA4677
晶片組	C741
記憶體容量	32 DIMMs (16 per CPU), 8 channels; Supports DDR5 , SDRAM DDR5 DIMMs (RDIMM, 3DS-RDIMM, and 9x4 RDIMM)
外觀尺寸 (深x 寬 x 高)	770 x 438.5 x 43.0 mm; 30.3” x 17.26” x 1.7”
儲存媒體插槽	2.5" sku SFF Hot-Swap (Tray-less) 3 x 4-port 2.5” NVMe(Gen4) 16 Gb/s NVMesupport：12 3.5" sku LFF Hot-Swap (Tool-less)：4
電源供應器	1+1 Max. 1600W CRPS Redundant Power Supply
前置指示燈	1 x Power Status, 1 x UID,1 x HDD Activity, 1 x System Status
前置控制	1 x Power On/Off, 1 x System Reset, 1 x UID, 1 x USB 3.0, 1 x USB 2.0
系統安全裝置	Option
風扇	FAN,404056,22900/23200RPM, non-hot swap
擴充槽	•Riser Slot #1 1 x single-width slot(Intel FCP1URISER1 1x PCIe 5.0 x16 supported) •Riser Slot #2 1 x Low Profile/Half Length (Intel FCP1URISER2 1 x PCIe 5.0 x16 supported) •Riser card (iPCFCP1URISER2KIT) Option: supports: 1 x Low Profile/Half Length,LowProfile/Half Length (1 x PCIe 5.0 x16 supported) PCIe Interposer Riser Slot (requires PCIe* Riser Card in Riser Slot #2) iPCFCP1URISER2KIT includes the PCIe interposer riser card, PCIe riser card, and PCIe interposer cable.
硬碟熱插拔背板	•2.5” SKU: 3 x 4-port 2.5” NVMe(Gen4) 16 Gb/s NVMe support. •3.5” SKU: 1 x 4-port 3.5” SAS/SATA3 12 Gb/s support.
淨重	22.5 KG/PCS
毛重	26.5 KG/PCS
