RM352 NVMe Gen4
3U NVMe Short-Depth Edge Computing Server Chassis
3U 6-Bay NVMe Gen 4 Edge Computing short-depth server chassis is designed for full-height expansion & hot-swap fan access.
Compare
Quick Search
  • By Chassis Type
  • By Motherboard
  • By RAID Card
  • By Power Supply
Compare
Features & Benefits
  • 450 mm ultra-short chassis fits various environments and is perfect for footprint minimization.
  • Optimized I/O design for machine learning in edge sites offering up to eight full-height PCIe expansion slots for GPU/FPGA accelerator cards.
  • Equipped with the latest tool-less design, storage, HDD trays, system fans, and PCIe riser brackets for easy NVMes and maintenance.
  • 3U 6-Bay NVMe Gen 4 Edge Computing Chassis (1600W 1+1) /3U 6-Bay NVMe Gen 4 Edge Computing Chassis/Option: 2-Bay NVMe Gen 4 H/S module.
  • Specification
  • Download
  • Accessory
  • Compatibility
  • Order Information
  • MB Form Factor SSI EEB (12” x 13”), CEB (12" x 10.5"), ATX (12" x 9.6")
    Dimension (D x W x H) 450.0 x 438.0 x 131.0 (mm) ; 17.72” x 17.24” x 5.15”
    Drive Bay 2.5" HDD, Hot-Swap, Front :6
    2.5" HDD, Hot-Swap, Rear (Option):2
    Storage Backplane 3 x 2 Port NVMe Gen 4 (U.2) Option: 2 Port NVMe Gen 4 (U.2)
    PSU Form Factor 2U Redundant CRPS (1+1), 1600W (80+, Platinum)
    Indicator 1 x Power Status , 2 x LAN Activity , 1 x UID , 1 x HDD Status , 1 x System Alarm
    Front Control 1 x Power On/Off, 1 x System Reset, 1 x UID, 1 x USB 3.0
    Cooling Fan Front: 4 x 80mm, PWM, 11000 RPM, Hot-swap
    Expansion Slot Opening 8 x Full Height (4 x Double-width GPU)
    Net Weight 11.595 KG/PCS
    Gross Weight 15.1 KG/CTN
    Cubic Feet 3.39
    Container Loading (Single Packing) 20' FCL: 154 PCS / 40' FCL: 336 PCS
  • Category Description Revision Size Download
    Datasheet RM352 NVME Gen4 Datasheet v1.0 v1.0 772.9 KB
  • Category Part. No# Description Support
    Click Part. No# to view item picture
  • Order Code
    RM35206H04*15869
    RM35206H04*15870
