RB238G13 Series
2U Dual Sockets Versatile Storage Server
Supports hybrid flash array, offering Intel VROC, Apache Pass, and Redfish compliance with remarkable thermal efficiency. Perfect for robust and efficient platforms in virtualization world.
Quick Search
  • By Chassis Type
  • By Motherboard
  • By RAID Card
  • By Power Supply
Features & Benefits
  • SAS/SATA HDD and NVMe SSD hybrid storage designed for software-defined storage applications
  • Built-in direct-attached NVMe drives to prevent bandwidth bottleneck
  • Scale-up storage space of internal M.2 SSDs equipped as an alternative OS drive
  • Efficient thermal solution to support 25W NVMe and 165W CPU
  • Tool-less drive carrier design for easy installation
  • Hot-swappable fan to mitigate the risk while fan running failure
  • Specification
  • Download
  • Accessory
  • Compatibility
  • Form Factor 2U
    CPU Intel Purley Platform , Cascade Lake Xeon Scalable Processor
    CPU Socket LGA3647
    Chipset Intel C621
    CPU Heatsink 2U Passive
    Memory Type DDR4 (Apache Pass Support)
    Memory Capacity Up to 2TB
    Max DIMM Slot 16 DIMMs
    Memory Speed 2666MHz
    Dimensions (D x W x H) 658.2 x 438.0 x 87.0 (mm)
    25.92" x 17.24" x 3.42"
    Drive Bay (U04) 2.5" SAS/SATA Drive:20
    (U04) NVMe Drive Hot-swap:4
    (U08) 2.5" SAS/SATA Drive:16
    (U08) NVMe Drive Hot-swap:8
    M.2 SATA or NVMe (2280/22110) (SATA RAID through RSTe):2
    PSU Form Factor 1+1 CRPS, 1200W
    Indicator 1 x System Power
    1 x UID
    1 x HDD Activity
    1 x System Status
    2 x LAN Activity
    Front Control 1 x System Power
    1 x UID
    1 x Reset
    2 x USB 2.0
    Cooling Fan Middele : 4 x 80mm (T=38mm), Hot-swap
    Expansion Slot 3 x PCIe Gen 3 @ x16 HH/HL
    1 x PCIe Gen 3 @ x8 HH/HL
    TPM Version TPM 2.0 Module
    USB 1 x USB 3.0 Port
    Video Integrated on AST2500 BMC, 16MB of DDR4 Video Memory
    Net Weight 23.0 kg
  • Category Description Revision Size Download
    Datasheet RB238G13 Series Datasheet V1.1 V1.1 1.8 MB
    Firmware Firmware Update SOP for BIOS & BMC with RB23824N4_N8_V1.0 V1.0 399.5 KB
    Firmware RB238G13-U08_N4_N8_BIOS_v3.0.1_BMC_v5.02 V3.0.1 33.4 MB
    User Manual RB238G13-U08 User Manual V1.0 V1.0 5.2 MB
