| 适应主板 |
ATX (12” x 9.6”), uATX (9.6” x 9.6”) |
| 机箱尺寸(深x 宽x 高) |
409.0 x 438.5 x 43.2 (mm) |
| 槽位 |
External: 2 x 2.5" HDD, Hot-swap, Front：
|
| 电源类型 |
1U Single 500W (80+ Gold)
|
| 指示灯号 |
1 x Power Status, 1 x HDD Activity
|
| 前板控制 |
1 x Power On/Off, 1 x System Reset, 2 x USB 3.0
|
| 安全装置 |
Intrusion Switch (Option)
|
| 风扇 |
Rear:
4 x 40mm (T:56mm), Dual Rotor,
22500/20500 RPM, PWM, Fix
Front:
4 x 40mm (T:56mm), Dual Rotor,
22500/20500 RPM, PWM, Fix |
| 扩展卡位 |
1 x PCIe x16 Riser Card, Supporting Full Height & Half Length
|
| 热抽拔背板 |
2-Port 12G SAS/SATA Backplane
|
